WIFI Digital Eyepiece 5.0MP


(New model)

The 2021 digital eyepiece model is stylish and compact. Its flexibility enables you to use on different microscopes.
Resolution: 5.0 MP
Frame rate: up to 30fps
Interface: WIFI, USB 2.0
Record format: Snapshot & Video
Operating System: All Windows, Android / iPhone/ Ipad
C-mount to microscope
Include powerful software with measurement and image management.
The software can be downloaded to multiple devices.

11 in stock

SKU: EDU1001 Categories: ,


Camera Specifications – Hardware configuration

Image SensorOnSemi AR0521
Expose modeRolling shutter
Maximum Resolution2592 x 1944 (5,038,848 pixels)
Sensor Optical Format1/2.5″
Pixel Size2.2 um x 2.2 um
Dynamic Range74.3 dB Linear, more than 96 dB (interleaved)
Spectral Characteristics380-650nm
Exposure Capability3.9ms – 320ms, Automatic and manual
White BalanceReal-time auto, Single auto, Manual adjustment
Maximum Transmission Frame RateUSB mode & WIFI mode: 30fps @ 2592×1944, 1920×1080, 1024×768, 640×480
Record formatSNAPSHOT – Picture Format: JPG, BMP, PNG, TIFF, PDF. Resolution: 2592×1944, 1920×1080, 1024×768, 640×480.

RECORD – Video Format: MJPG format AVI file. Resolution: 1920×1080, 1024×768, 640×480.
Micro USB Interface
Wired: USB2.0 DC 5.0V 500mA. Wireless: USB2.0 DC 5.0V 1500mA
Camera InterfaceC Port to the microscope
Camera Specifications -Wireless Parameter
IEEE 802.11ac
Operating Frequency Range
5.180-5.825 GHz

Camera Specifications -Software environment

Windows system demandMicrosoft Windows XP/7/8/8.1/10 (32 & 64 bit)
CPU: Dual-core 3.0 Ghz or more CPU
Memory: 4G or more
At least 10 GB avaiable hard disk space
Wireless network card (support IEEE 802.11ac)
IOS System DemandIphone X/ 8/ 8 Plus/ 7/ & Plus/ 6s/ 6s Plus, Ipad Pro (12.9 inch 2nd generation)/ (12.9-inch 1st generation) / (10.5 inch) / (9.7 inch), Ipad Air 2/ Ipad mini 4
IOS11.0 or higher
Android system demandAndroid 5.0 or higher
CPU: dual-core 1.7 GHz or higher
RAM memory: 1G or more
Storage ROM: suggest 8G or larger

Additional information

Weight 1 kg
Dimensions 17 × 8 × 29 cm
